Low Frequency Electronic Ear Tag Wand Reader

Low Frequency Electronic Ear Tag Wand Reader

Product name: Low frequency electronic ear tag wand reader Model: RL07 Bluetooth connection: equipped with BLE and SPP Bluetooth communication methods Protocol standards: ISO -11784/5, FDX-B and HDX Working frequency: 134.2Khz
Product Details

  Lepson RL07 electronic ear tag reader uses wireless radio frequency technology, integrates reading, display and Bluetooth data transmission functions, and transmits animal ear tag data to the terminal.

Product Name Low frequency electronic ear tag wand reader
Model RL07
Bluetooth Connection Equipped with BLE and SPP Bluetooth communication methods
(Support iOS, Android, Windows systems)
Protocol Standards ISO -11784/5、FDX-B 和 HDX
Working Frequency 134.2Khz
Readhead Size 50mm
Length 45cm to 120cm
Weight 0.3kg
LCD Screen 2.08 inches
Charging Method USB port charging
Temperature Range: Operating temperature: -10℃ to 50℃ Storage temperature: -20℃ to 65℃
Battery Capacity: 3000mAh
Continuous Working Time 16 hours
Reading Distance 12 cm
Waterproof Level Reading head waterproof grade: IPX5 Body waterproof grade: IPX3

1. Key function:

The buttons are multi-functional and have different functions in different modes.



①---Set button

②---Confirm button

③---Power/Scan button

※Press Power/Scan; press the button to start the reader, the name and model of the device will be displayed on the LCD screen for a short time, and then it will be replaced by the preparation for measurement interface.

※Press and hold the power/scan button for a few seconds to turn off the phone.

※Press the Power/Scan button to start scanning, or press the Confirm button to exit the scanning operation.

※If the device is idle for 10 minutes, it will automatically shut down.

2.Bluetooth connection:

The device has BLE and SPP Bluetooth communication methods and can be connected by iOS/Android/Windows systems.

3.Scan electronic ear tag:

Press the power/scan button to start scanning as shown below:

Scan interface
  Within 10 seconds, if no ear tag is scanned, the following information will be displayed on the screen. You can press the power/scan button to restart scanning.
If the ear tag is scanned, the ear tag data will be displayed on the screen as shown below:

Ear tag data display

If Bluetooth communication is normal, the ear tag data will be automatically transmitted to the terminal, as shown below:

4. Maintenance charging:

When the battery power is low, the reader needs to be charged. Unscrew the back cover and connect the USB charger and charging cable.

During the charging process, the battery indicator light will turn red, the lightning bolt logo on the screen will flash, and the lit battery bar will indicate the charged level.

After a few seconds, the device goes into sleep mode. Check the charging status by pressing the Power/Scan button. If the battery indicator light goes out, it means the battery is fully charged. Unplug the USB charging cable and screw on the back cover. Note: The device cannot be powered on during charging.

5.Cleaning

Regular cleaning of equipment is necessary. Can be cleaned with soft cloth or paper. The readhead is IPX5 waterproof and can be flushed directly with water.

6.Storage

When the equipment is not in use, the equipment should be kept in its case and protected from extreme temperatures.

7. Maintenance

Please be careful before, after and during use of the equipment. Do not drop the device from high places. Avoid high voltage on the LCD screen.

Charge the battery regularly.
